Designed and built for professional environments, the full-depth MP-M30 pairs glass swing doors with front neck storage and a robust aluminium structure, making it as practical in a restaurant or hotel as it is striking. Part of the modular MOD range, it can be installed freestanding or built in and combined with other modules to create a stunning Wine Wall.

Key Features
  • Full-depth shelving with front-neck bottle positioning for easy access and clear label visibility
  • Swing-door access — available with glass doors front and back, or glass front with solid back
  • Glass-back variant allows light to pass through the cabinet, turning storage into display
  • Solid-back variant offers a clean, enclosed rear wall for seamless integration into professional fitouts
  • Part of the MOD modular system — units can be combined to create larger, bespoke configurations
  • Designed for commercial use: hospitality venues, wine bars, restaurants, and considered retail environments
  • Full aluminium structure with a choice of frame finishes to suit traditional or contemporary interiors
  • Warm white LED lighting throughout
  • Multi-temperature operation — configurable for white wines, red wines, or a mixed-temperature setup
Taxes included. Shipping calculated at checkout.
Configuration
Use Case

Want to order this product?

Complete the short enquiry form or call

01395 904829
View full details

Description

The MOD 30 range from Della Marta are single-temperature, luxury wine cabinets with swing doors and front neck bottle storage, designed for commercial use. Models within the range can be placed freestanding or be built into a wall recess or alcove, depending on your preference. The modular design allows you to combine with taller cabinets to create a stunning Wine Wall. Made with a full aluminium structure, you can also choose a finishing to suit traditional or linear styles. Choose a frame style that complements your decoration and, for added uniqueness, you can even combine multiple modules to create a Wine Wall.

Commercial Use Models

mp-m30
MP-M30
  • 64 bottle capacity
  • Warm white LED lighting
  • Solid back with swinging glass door
  • W900 x H1050 x D515mm
  • Weight 67kg
  • Noise level 42dB
Technical Specification: MP-M30 (PDF)
mp-c30
MP-C30
  • 64-68 bottle capacity
  • Warm white LED lighting
  • Double swinging glass doors both sides
  • W900 x H1050 x D520mm
  • Weight 83kg
  • Noise level 42dB
Technical Specification: MP-C30 (PDF)

Temperature Settings

Red Wines

Internal Finishing
Anodized Aluminium Matt Black

Key Features

Single Temperature Zones:
  • Range of 14 to 16°C
*64 Bottle Capacity:
  • Maximum storage capacity based on Bordeaux shape bottles, other bottle formats may reduce capacity
Energy Efficient:
  • The MOD 30 range feature single temperature zones, with low energy consumption and various options depending on fan settings and temperature settings. Control is achieved through a digital panel, managing lighting, fans and defrost cycles

Interior & Exterior

The MOD 30 range features swinging doors with a double glazed, UV-treatment to safeguard your collection. Lit by warm white LED lighting, the interior boasts a high-quality aluminium construction. An automatic defrost and evaporation system maintain optimal storage conditions, with lockable doors for added security.

A Note About Installation

For proper installation, built-in models need a 30mm gap behind them to prevent overheating and ensure a sufficient airflow. This gap ensures effective ventilation, preventing vibrations and enabling warm air to escape. It is essential to have ample clearance between the floor and the lower section of the wine wall to maintain unrestricted airflow.

Specifications

Bottle capacity up to 64-68 bottles
Width 900mm
Depth 515mm-520mm (full)
Height 1050mm
Power supply 230 V / 50–60 Hz
Refrigerant R-600a (natural)
