Mod-20
Mod-20
The shallow-depth, undercounter and modular MD-H20, fitted or freestanding, holds up to 24 horizontal bottles behind lockable double glass doors with warm white LED lighting. A multi-zone wine cabinet from the MOD range, temperatures range from +4°C to +20°C and whisper-quiet at 37 dB.
Key Features
Key Features
- Horizontal shelving throughout — keeps every bottle correctly presented and easy to read at a glance
- Swing glass doors for clear visibility and straightforward access
- Choice of shallow or full depth to suit the space available
- Solid or glass rear wall — solid back for alcove and built-in installation, glass back for full through-display
- Domestic and commercial configurations available within the same range
- Freestanding or built-in to a wall recess or alcove
- Full aluminium structure with a choice of frame styles and internal and external finishes
- Multi-temperature capability — configurable for white wines, red wines, or a combination of both
- Warm white LED lighting throughout
- Door lock as standard
- Modules can be combined to create a larger, bespoke installation
Taxes included.
Shipping calculated at checkout.
Quantity
Want to order this product?
Complete the short enquiry form or call
Request a Quote
Mod-20
Description
The MOD 20 range from Della Marta are multi-temperature, luxury wine cabinets with horizontal bottle storage, designed for home or commercial use. Models within the range can be placed freestanding or be built into a wall recess or alcove, depending on your preference. The modular design allows you to combine with taller cabinets to create a stunning Wine Wall. Made with a full aluminium structure, you can also choose a finishing to suit traditional or linear styles. Choose a frame style that complements your decoration and, for added uniqueness, you can even combine multiple modules to create a Wine Wall.
Home Use Models
|
|
MD-H20
|
 |
MD-M20
|
 |
MD-C20
|
Commercial Use Models
|
|
MP-H20
|
 |
MP-M20
|
 |
MP-C20
|
Temperature Settings
 |
 |
 |
 |
| Red & White Wines | Red Wines | White Wines | Red Wines |
Internal Finishing
|
|
|
| Anodized Aluminium | Matt Black |
Frame Options
|
|
|
|
| Plain Frame | Moulded Frame | Fit Clad |
Key Features
Multiple Temperature Zones:
- Range of 4 to 20°C
Multiple Depths Available:
- Various depth options to suit your needs
*24 or 48 Bottle Capacity:
- Maximum storage capacity based on Bordeaux shape bottles, other bottle formats may reduce capacity
Energy Efficient:
- The MOD 20 range feature multiple temperature zones, with low energy consumption and various options depending on fan settings and temperature settings. Control is achieved through a digital panel, managing lighting, fans and defrost cycles
Interior & Exterior
The MOD 20 range features swinging doors with a double glazed, UV-treatment to safeguard your collection. Lit by warm white LED lighting, the interior boasts a high-quality aluminium construction. An automatic defrost and evaporation system maintain optimal storage conditions, with lockable doors for added security.
A Note About Installation
For proper installation, built-in models need a 30mm gap behind them to prevent overheating and ensure a sufficient airflow. This gap ensures effective ventilation, preventing vibrations and enabling warm air to escape. It is essential to have ample clearance between the floor and the lower section of the wine wall to maintain unrestricted airflow.
Specifications
| Bottle capacity | up to 48 bottles |
|---|---|
| Width | 900mm |
| Depth | 363mm (shallow) or 515mm-520mm (full) |
| Height | 903mm |
| Power supply | 230 V / 50–60 Hz |
| Refrigerant | R-600a (natural) |
